Product resources
Overview
6" Rigid Alligator Clip with 4 mm Banana Jack Interconnect. Ideal for high current application, alligator style contact can grasp terminals to 12.7 mm (0.50") in diameter. Rigid housing allow increased current capacity. Insulation on alligator contacts protects against shorting.
- Materials: Body: Polyamide (Nylon); Contact tip: Brass, Nickel Plt.
Models
| Image | Model | Description | MSRP | Status | Warranty | Type | Color | Rated Voltage | Max Current | Operating Temperature | UOM |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
CT2965-0 | Rigid Alligator Clip - Black | $30.00 | Active Catalog | 1 Year | Alligator | Black | 1,000 V CAT III | 20 A | -20° to +80° C | EA |
 |
CT2965-2 | Rigid Alligator Clip - Red | $30.00 | Active Catalog | 1 Year | Alligator | Red | 1,000 V CAT III | 20 A | -20° to +80° C | EA |
Specifications
- Type
- Alligator
- Color
- Black
- Rated Voltage
- 1,000 V CAT III
- Max Current
- 20 A
- Operating Temperature
- -20° to +80° C
- Export Control Classification Number (ECCN)
- EAR99
- REACH Compliance
- Compliant
- RoHS Compliance
- RoHS 2 (2015/863/EU) Compliant
- Schedule B Number
- 8536.90.4000
- Country of Origin
- France
- Lead Time
- 56 days
- See More Specifications
- Datasheet
Documents
- DatasheetDatasheet
- REACH StatementCompany Document
- RoHS DirectiveCompany Document
- PFAS - Certificate of ComplianceCompany Document
