Overview
Sprung Hook for 5 mm oscilloscope probes. Fits both the 5 mm General Purpose and GE series oscilloscope probes. Special 'snap-locking' feature holds the accessory firmly to the probe.
- 3 Colors available - Black, Red & Grey
- Snap-lock feature
Models
| Image | Model | Description | MSRP | Status | Warranty | Type | Accessory Type | Max Current | Color | UOM |
|---|---|---|---|---|---|---|---|---|---|---|
 |
CT2709A-0 | Sprung Hook, Black, 5mm (Snap-Lock) | $6.65 | Active Catalog | 1 Year | 5mm | 5 mm Sprung Hook | 1 A | Black | EA |
 |
CT2709A-2 | Sprung Hook, Red, 5mm (Snap-Lock) | $6.65 | Active Catalog | 1 Year | 5mm | 1 A | Red | EA | |
 |
CT2709A-8 | Sprung Hook, Grey, 5mm (Snap-Lock) | $6.65 | Active Catalog | 1 Year | 5mm | 1 A | Grey | EA |
Specifications
- Type
- 5mm
- Max Current
- 1 A
- Color
- Red
- Export Control Classification Number (ECCN)
- EAR99
- REACH Compliance
- Compliant
- RoHS Compliance
- RoHS 2 (2015/863/EU) Compliant
- Schedule B Number
- 9030.90.8010
- Country of Origin
- Taiwan
- Lead Time
- 98 days
- See More Specifications
- Product Drawing
Documents
- Product DrawingProduct Drawing
- REACH StatementCompany Document
- RoHS DirectiveCompany Document
- PFAS - Certificate of ComplianceCompany Document
